2 inch gear oil pump model KCB 200

Description

Saiken brand gear oil pump Model “KCB/YCB” (Rotary Twin Gear Pump – oil Gear Pump – Positive Displacement Pump – External Gear Pump) Heavy duty foot mounting type positive displacement rotary twin gear pump. Model “KCB/YCB”having three piece construction it can be easily cleanable and maintainable. These pumps having a double helical refined gear and hardened grind finished shaft, double helical gear prevent axial load & side thrust which is help to increase life and performance of pump.

The self lubricated needle roller bearing type, Used for clean viscous liquid having sufficient lubricating property such as clean lube oil, Gear oil, Animal oil, Fish oil, Hydraulic oil, Honey, Vegetable oil, SAE lubricating oil for continues duty, However Intermittent duty Bush Bearing for small size pump

KCB 200 Gear Oil Pump Specifications：

Model	Capacity   (L/min)	Pressure   (Bar)	Speed   (rpm)	Caliber   (inch)	Power   (kw)	Efficiency
KCB-200 (2CY12/0.33)	200 (53gpm)	3.3	1420	2	4	46%

The pump is designed to pump light fuel oils such as diesel, kerosene and bio diesel. It can also pump vegetable oil, motor oil, and even glycerin (a waste product from the biodiesel process). However, the viscosity of the working fluid will largely determine whether the pump can handle it. If these thicker oils are fluid media, especially if they are below 100°F, the pump operation cycle may be discontinuous. A gear pump is a pump connected to a motor by a shaft. The pump itself is all metal (metal gear) and can pump hot fluid without affecting the motor. High power motor, with thermal protection function, automatically shut down the pump when there is danger of overheating. These pumps produce strong suction and are self-priming. They dry up for only a moderate amount of time, allowing the use of suction hoses to collect liquid from the tank. They should not be idling for long periods as oil is needed to lubricate the pump head. The metal gears that drive the pumping action can handle a lot of fluid, even if it’s partially dirty. In the case of vegetable oil, any soft particles will pass straight through the pump without problem and are often pulverized by the gears. Do not let metal and other hard materials through the pump, otherwise it may damage the gear.

KCB gear oil pump model data sheet：

KCB Pump	Size		Rated Flow			Pressure		Rated Speed	Motor Power
Model	Inch	mm	m3/h	LPM	GPM	Bar	Psi	RPM	kW	Hp
KCB18.3	3/4”	20	1.1	18.3	5	14.5	210	1450	1.5	2
KCB33.3	3/4”	20	2	33.3	9	14.5	210	1450	2.2	3
KCB55	1”	25	3.3	55	15	3.3	52	1450	1.5	2
KCB83.3	1-1/2”	40	5	83.3	22	3.3	48	1450	2.2	3
KCB135	2”	50	8	133	35	3.3	48	960	2.2	3
KCB200	2”	50	12	200	53	3.3	48	1450	4	5.5
KCB300	3”	80	18	300	79	3.6	52	960	5.5	7.5
KCB483.3	3”	80	29	483.3	128	3.6	52	1450	11	15
KCB633	4”	100	38	633	167	2.8	40	960	11	15
KCB960	4”	100	58	960	254	2.8	40	1450	22	30
KCB1200	6”	150	72	1200	317	6.0	87	740	37	50
KCB1600	6”	150	95	1600	423	6.0	87	980	45	61
KCB1800	8”	200	112	1800	476	6.0	87	740	55	75
KCB2500	8”	200	150	2500	661	6.0	87	980	75	102
KCB2850	10”	250	171	2850	753	6.0	87	740	90	123
KCB3800	10”	250	230	3800	1004	6.0	87	980	110	150
KCB4100	10”	250	246	4100	1083	6.0	87	740	132	180
KCB5400	10”	250	324	5400	1427	6.0	87	980	160	220
KCB5600	14”	350	336	5600	1480	6.0	87	740	160	220
KCB7600	14”	350	460	7600	2008	6.0	87	980	200	272
KCB7000	14”	350	420	7000	1849	6.0	87	740	185	252
KCB9600	14”	350	570	9600	2536	6.0	87	980	250	340
